Aircraft

Aircraft

Size (unfolded, excluding propeller blades)

810×670×430 mm (L×W×H)

Bare weight (with regular propeller blades)

Without battery: 5020 ± 20 grams; With battery: 9740 ± 40g
The weight of the product may vary due to different material batches and other reasons. Please refer to the actual product for accuracy.

Size (Folding)

430×420×430 mm (L× W ×H)

Maximum takeoff weight

15.8 dry grams

Diagonal motor wheelbase

895 mm

Size

Unfolding dimensions: length 980mm, width 760mm, height 480mm (including tripod)

Empty weight (including lower single pan tilt bracket)

About 3.77kg (excluding battery); Approximately 6.47kg (including dual batteries)

Folding and Size: Length 490 millimeters, Width 490 millimeters, Height 480 millimeters (including tripod and gimbal)
At the maximum projection size excluding the propeller blades

Maximum load capacity of single gimbal shock-absorbing ball

960g

Aircraft box dimensions: 779mm in length, 363mm in width, and 528mm in height

Maximum takeoff weight

9.2kg

Maximum load capacity

6 kilograms
The 6kg load data was measured at sea level using the third gimbal component. As the altitude increases, the load-bearing capacity will decrease. Please refer to the official user manual for details.

Operating frequency

2.4000 GHz-2.4835 GHz

Blade size

25 inches

5.150-5.250 GHz (CE: 5.170-5.250 GHz)

Wheelbase

Diagonal: 1070 millimeters

5.725 GHz-5.850 GHz

Maximum ascent speed

10 meters per second

Some regions do not support the 5.2GHz and 5.8GHz frequency bands, and in some regions, the 5.2GHz frequency band is only for indoor use. Please refer to local laws and regulations for details.

Maximum descent speed

8 meters per second

Transmitting power (EIRP)

2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)

Maximum horizontal flight speed (no wind near sea level)

25 meters per second

5.1 GHz: <23 dBm (CE)

Maximum takeoff altitude

7000 meters

5.8 GHz: <33 dBm (FCC/SRRC), <14 dBm (CE)

Maximum flight time (windless environment)

59 minutes
In a windless environment, the aircraft only carries H30T (with a total weight of 10670 grams) and flies forward at a constant speed of 10 meters per second at sea level until the remaining 0% battery is measured. The data is for reference only, and the results may vary to varying degrees depending on different external environments, usage methods, and firmware versions.

Hovering accuracy (in windless or slightly windy environments)

Vertical:

Maximum hover time (windless environment)

53 minutes
In a windless environment, the aircraft is only equipped with H30T (with a total weight of 10670 grams), hovering at sea level until the remaining 0% power is measured. The data is for reference only, and the results may vary to varying degrees depending on different external environments, usage methods, and firmware versions.

+0.1m (when visual positioning is working normally)

Maximum range (windless environment)

49 kilometers
In a windless environment, the aircraft only carries the H30T (with a total weight of 10670 grams) and flies forward at a constant speed of 17 meters per second at sea level until the remaining 0% battery is measured. The data is for reference only and may vary to varying degrees depending on the external environment, usage, and firmware version

+0.5m (when GNSS is working normally)

Maximum wind resistance speed

12 meters per second
The maximum allowable wind speed during takeoff and landing phase

+0.1m (when RTK positioning is working normally)

Maximum heading angular velocity

Heading axis: 100%/s

Level:

Maximum tilt angle

35°

+0.3m (when visual positioning is working normally)

Working environment temperature

-20 ° C to 50 ° C (without solar radiation)

+1.5m (when GNSS is working normally)

GNSS

GPS + Galileo + BeiDou + GLONASS*
*GLONASS is only supported when the RTK module is turned on.
Standard sky end ADS Bin, equipped with dual antennas, supporting 20 kilometer reception

RTK position accuracy (in RTK FIX)

0.1m (when RTK positioning is working normally)

Hovering accuracy (in windless or slightly windy environments)

Vertical:

1cm+1ppm(Level)

+0.1 meters (when visual positioning is working normally)

1.5cm+1 ppm(Vertical)

+0.5 meters (when satellite positioning is working normally)

Maximum rotational angular velocity

Pitch axis: 300 °/s, heading axis: 100 °/s

+0.1 meters (when RTK positioning is working normally)

Maximum pitch angle

30 ° (25 ° when using N gear and front vision system enabled)

Level:

Maximum ascent speed

6m/s

+0.3 meters (when visual positioning is working normally)

Maximum descent speed (vertical)

5m/s

+0.5 meters (when satellite positioning is working normally)

Maximum tilt descent speed

7m/s

+0.1 meters (when RTK positioning is working normally)

Maximum horizontal flight speed

23 m/s

RTK positioning accuracy

RTK fixed solution:
Level: 1 centimeter+1 ppm; Vertical: 1.5 cm+1 ppm

Maximum flight altitude

5000m (using 2110s propeller blades, takeoff weight ≤ 7.4kg) 7000m (using 2112 plateau silent propeller blades, takeoff weight ≤ 7.2kg)

RTK direction finding

Support, accuracy<2 °

Maximum tolerable wind speed

12m/s

Sky end ADS Bin

Standard configuration, dual antennas, supporting 20 kilometers

Maximum flight time

55 minutes
In a windless environment and in an unloaded state, the remaining 0% battery was measured by flying forward at a speed of approximately 8m/s. This is for reference only, and the actual usage time may vary depending on the flight mode, accessories, and environment. Please pay attention to the app prompts.

Onboard memory

None

Compatible with DI gimbal

Zenmuse H20/H20T/H20N/P1/L1/L2

Body interface

USB-C debugging interface x1: USB2.0
E-PortV2 interface x4: located at the lower part of the body, with a single port power of 120 watts
Enhanced image transmission module interface x2: located on the belly of the aircraft

Support pan tilt installation method

Top mounted single gimbal, bottom mounted single gimbal, bottom mounted dual gimbal, bottom mounted single gimbal+top mounted single gimbal, bottom mounted dual gimbal+top mounted single gimbal

Propeller model

2510F

IP protection rating

P55
The protection level is not a permanent standard, and the protection ability may decrease due to product wear and tear.

Navigation light

Built in drone

GNSS

GPS+GLONASS+BeiDou+Galileo

IP protection rating

IP55
The protection level is not a permanent standard, and the protection ability may decrease due to product wear and tear.

Working environment temperature

20 ° C to 50 ° C

Motor model

7510
